LG GCW1069CS Service Manual

35
9. Tilt the CABINET COVER.
10. Disconnect the DOOR S/W connector.
※※
NOTE: When assembling the CABINET
COVER, connect the connector.
11. Lift and separate the CABINET COVER.
8. Unscrew the screw from the lower side of the CABINET
COVER.
1. Disassemble the CABINET COVER
(refer to page 32).
2. Disassemble the CLAMP ASSEMBLY.
3. Disassemble the GASKET.
TUB GASKET
CLAMP
GASKET
