34
1. Disassemble the CONTROL PANEL ASSEMBLY
(refer to page 29).
2. Open the DOOR.
3. Disassemble the CLAMP ASSEMBLY.
4. Unscrew the 4 screws from the upper part of the
CABINET COVER.
5. Unscrew the screw from CAP COVER.
6. Unscrew the screw from inside CAP COVER.
7. Put a flat (
-
) screwdriver or putty knife into both sides
of the CAP COVER, and pull it out.
To Next Page
