 Installation of Auto dosing system
 Auto dosing interface
CH DetergentInput period
£
Main wash Main wash phase
¤
Bleach
Main wash(Remaining w
ashing me: 5 Minutes)
¥
Soener Final rinse phase
¦
Pre-wash Pre-wash phase
ʹ͹ ΅ΪΡΖ
ΈΚΣΖ
ʹΠΝΠΣ
΄ΚΘΟΒΝ
΅ΪΡΖ
ྙ ;ΒΚΟΈΒΤΙ΃ΖΕ +
ྚ ͳΝΖΒΔΙ ͳΝΦΖ +
ྛ ΄ΠΗΥΖΟ ΖΣ ΊΖΝΝΠΨ +
ྜ ΁ΣΖΈΒΤΙ ΀ΣΒΟΘΖ +
ྜྷ ͳΣΠΨΟ +
ྠ ͳΝΒΔΜ -
1
2
3 4 5
8
Skip
Auto dosing interface
Back of Washer
Wire Color
Black: Jump wire (- signal )
Red: Main Wash (+ si gnal)
Blue: Bleach (+ si gnal )
Yellow: Soener (+ signal )
Orange: Pre-Wash (+ signal)
Brown: Not Us ed (+ si gn al)
1
2
3
4
※ Dosing time should be set according to the flow rate of the pump. We recommend not exceeding 30mL
for detergent and 50mL for Bleach/Softener. Refer to detergent/chemical instructions to determine the
dosing time for optimal performance.
