- 12 -

Only for training and service purposes

2. PERFORMANCE

GD910 service manual

WCDMA Transmitter spec.

Item Specification

Transmit Frequency WCDMA2100 : 1920 ~1980 MHz

Maximum Output Power +24 dBm / 3.84 MHz, +1 / -3 dB

Frequency Error within ±0.1 PPM

Open Loop Power Control Normal Conditions : within ±9 dB,

Extreme Conditions : within ±12 dB

Minimum Transmit Power < -50 dBm /3.84 MHz

Occupied Bandwidth < 5 MHz at 3.84 Mcps (99% of power)

Adjacent Channel Leakage

Power Ratio (ACLR)

> 33 dB @ ±5 MHz,

> 43 dB @ ±10 MHz

Spurious Emissions

|f-fc| > 12.5 MHz

< -36 dBm / 1 kHz RW @ 9 kHz ≤ f < 150 kHz

< -36 dBm / 10 kHz RW @ 150 KHz ≤ f < 30 MHz

< -36 dBm / 100 kHz RW @ 30 MHz ≤ f < 1 GHz

< -30 dBm / 1 MHz RW @ 1 GHz ≤ f < 12.75 GHz

< -41 dBm / 300 kHz RW @ 1893.5 MHz < f < 1919.6 MHz

< -67 dBm / 100 kHz RW @ 925 MHz ≤ f ≤ 935 MHz

< -79 dBm / 100 kHz RW @ 935 MHz < f ≤ 960 GHz

< -71 dBm / 100 kHz RW @ 1805 MHz ≤ f ≤ 1880 MHz

Transmit Intermodulation < -31 dBc @ 5 MHz & < -41 dBc @ 10 MHz

when Interference CW Signal Level = -40 dBc

Error Vector Magnitude < 17.5 %, when Pout ≥ -20 dBm

Peak Code Domain Error

< -15 dB at Pout t -20 dBm
