Chapter 5 Frame Editor
5-6
5.2.1 Basic parameter setting
Basic parameters are for setting communication specification of communication module to decide communication
speed, parity, data bit, stop bit and modem service as required. If modem communication is applied, command for
initializing modem shall be input. (Command for initializing modem may depend on makers, however, mostly set to
‘ATZ’.) [Table 5.2] describes items of basic parameters which are to be set basically. Basic parameters are set
respectively according to channels of RS-232C and RS-422 with setting values saved respectively per
communication channel. [Figure 5.2] shows setting screen of each item in basic parameter screen.
[Table5.2] Setting items of basic parameters
Setting item Contents Remark
Station
Set module station No. used in dedicated mode and other
company’s dedicated mode
stations 0~31
If communication channel is RS-232C, set to communication
type of RS-232C channel
Null modem / Modem /
Dedicated modem
Type
If communication channel is RS-422, set to communication
type of RS-422 channel
RS-422/RS-485
Baud Rate Set communication speed per channel 300~76800 bps
[Note1]
Data bit Number of data bits in asynchronous communication type 7~8 bits
Stop bit
Number of stop bits required for asynchronous communication
type
1~2 bits
Parity Number of parity bits for checking data error None/Even/Odd
Init command Initializing command of dial-up modem if modem used Default value is ATZ
Monitor Entry Number of monitors registerable in dedicated mode 4X32 or 16X20
Remark
[Note1] Communication speeds can be set up to 38400bps for RS-232C channel and up to 76800bps for RS-422
channel
