Chapter 1 Introduction
1-2
1.1 Module selection per CPU type
As 4 types of the modules are developed according to CPU types, appropriate module shall be selected for CPU type
and its service. [Table1.1] describes selection guide of module per CPU type.
[Table1.1] Module selection per CPU type
CPU type Module name
Number of
channel
Configuration supported
Max. number
mountable
[Note2]
GLOFA-GMR
[Note1]
G3L-CUEA 2 RS-422 8
[Note3]
GLOFA-GM1 G3L-CUEA 2 RS-232C/RS-422 8
GLOFA-GM2 G3L-CUEA 2 RS-232C/RS-422 8
GLOFA-GM3 G3L-CUEA 2 RS-232C/RS-422 8
GLOFA-GM4 G4L-CUEA 2 RS-232C/RS-422 4
G6L-CUEB 1 RS-232C 4
GLOFA-GM6
G6L-CUEB 1 RS-422 4
G7L-CUEB 1 RS-232C 1
GLOFA-GM7
G7L-CUEC 1 RS-422 1
Remark
[Note1] RS-422 channel only is available if mounted on duplicated base.
[Note2] This module can not be mounted on an extended base but on the basic base only.
[Note3] However, it can be mounted on slots No. 0~3 of duplicated extended base (for 8 slots) with max. 8 modules.
