15
INSTALLATION
1
Remove the top hinge cover screws .
Lift the hook (not visible), located at the
bottom of the front side of the cover
,
with a at-head screwdriver.
2
Remove the three bolts using a 10mm or
13/32-inch socket wrench and lift o the
top hinge. Set parts aside.
Removing the Refrigerator Door
WARNING
When lifting the hinge, be careful that
the door does not fall forward.
3
Lift the door from the middle hinge pin and
remove the door.
WARNING
Place the door, inside facing up, on a
non-scratching surface.
1
Make sure that the plastic sleeve is
inserted in the bottom of the door. Lower
the door onto the middle hinge pin as
shown in the gure.
2
Line up the top hinge with the holes in the
top of the refrigerator. Use the three bolts
to replace the hinge. Tighten the bolts.
Assembling the Refrigerator Door
3
Replace the cover. Insert and tighten the
cover screws
.
ENGLISH
