31
7-3. RESISTANCE SPECIFICATION OF SENSOR
TEMPERATURE SENSOR
°F (°C)
RESISTANCE OF REFRIGERATOR
(DEFROST) SENSOR
-4 -20 77 KW
5 -15 66 KW
14 -10 47.3 KW
23 -5 38.4 KW
32 0 30 KW
41 +5 24.1 KW
50 +10 19.5 KW
59 +15 15.9 KW
68 +20 13 KW
77 +25 11 K W
86 +30 8.9 KW
104 +40 6.2 KW
122 +50 4.3 KW
1. The resistance of SENSOR HAS 5% common difference.
2. Measure the resistance of SENSOR after leaving it over 3 minutes in measuring temperature. This
postponing is necessary because of perceiving speed.
