POWER: This unit operates on a mains supply of
200-240V~, 50/60Hz.
WIRING: This unit is supplied with a BSI 1363 approved
13 amp mains plug, fused at 5 amp. When replacing the
fuse always use a 5 amp BS 1362, BSI or ASTA approved
type. Never use this plug with the fuse cover omitted.
To obtain a replacement fuse cover contact your dealer.
If the type of plug supplied is not suitable for the mains
sockets in your home, then the plug should be removed
and a suitable type tted. Please refer to the wiring
instructions below:
WIRING: A mains plug removed from the mains lead of
this unit must be destroyed. A mains plug with bared
wires is hazardous if inserted in a mains socket. Do not
connect either wire to the earth pin, marked with the
letter E or with the earth symbol or coloured green
or green and yellow. If any other plug is tted, use a 5
amp fuse, either in the plug, or at the distribution board.
IMPORTANT: The wires in this mains lead are coloured
in accordance with the following codes:
- BLUE: NEUTRAL, BROWN: LIVE - As the colours of the
wires in the mains lead of this unit may not correspond
with the coloured marking identifying the terminals
in your plug, proceed as follows: The wire which is
coloured blue must be connected to the terminal
which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected
to the terminal which is marked with the letter L or
coloured red.
