Introduction
OPEN/CLOSE button
TUNING(-/+)
/SKIP(
..
bb/BB
>>
)
buttons
Remote sensor
PHONES connector
VOLUME controller
STANDBY/ON
STANDBY indicator
Lights red when the
receiver is in Standby
mode (off).
DISPLAY Window
DISC Tray
Do not touch the inner pins of the jacks on the rear
panel. Electrostatic discharge may cause
permanent damage to the unit.
USB port
Connect to a USB port of
a memory device
(USB memory etc.)
FUNC./PLAY
Press and hold down this button about 3
seconds, then press repeatedly to select
other function.
MONO/ST./
P./STEP
STOP
AUDIO
L
R
HDMI OUTHDMI OUT
S-VIDEO OUT connector
FM Antenna connector
AM Loop Antenna connectors
SPEAKER connectors
Power Cord
MONITOR OUT connector
COMPONENT VIDEO OUT terminals
Connect to a TV with Y Pb Pr inputs.
AV2 AUDIO Input (L/R)/VIDEO IN Connectors
Front Panel/Rear Panel
OUTPUT (TO TV)
EURO AV socket
Connect to a TV with
SCART jack.
HDMI OUT
HDMI output
providing a high
quality
interface for digital
audio and video.
Cooling fan
OPTICAL IN
connector
