25
IF BOARD
ITEM P/N Description Usage Location
790621300600R PCBA,IF BOARD, LE1730-6E0
10 790621320600R PCBA,IF BOARD,OTHRS,LE1730-6E0 1
20 790621340600R PCBA,IF BOARD,SMD, LE1730-6E0 1
30 629030006500R PROGRAM, LE1730-6E0 1
40 511130002202R SOLDER PASTE,Sn95.5%Ag3.9%Cu0.6% 0
40 511130002201R SOLDER PASTE,Sn96.5%Ag3.0%Cu0.5% 0
40 511130002200R SOLDER PASTE,Sn96.5-Ag3.0-Cu0.5 ROHS 0.43714
50 511130001200R SOLDER BAR,Sn96.5/Ag3.0/Cu0.5/Ni0.06/Ge0 0.96571
60 511130000300R SOLDER WIRE,Sn96.5/Ag3.0/Cu0.5/Ni0.06/Ge 0.0667
70 511140000701R
FLUX Grade 0.812±0.010
3.45
ITEM P/N Description Usage Location
790621320600R PCBA,IF BOARD,OTHRS,LE1730-6E0
10 420431000260R
CAP EC 10uF 25V M,105
℃
ST 5x11 RoHS
2 C111,C144,
20 420431010461R
CAP EC 100uF 16V M,105℃ ST 5x11(SK) RoH
2 C101,C102,
30 420432200460R
CAP EC 22uF 16V M,105℃ ST, 5x11,RoHS
5 C130,C133,C142,C145,C1
05,
40 420432210460R
CAP EC 220uF 16V M,105
℃
ST 6.3x11 RoHS
1 C108,
50 430631060020R
WAFER 2.0mm 6P 180
°
,RoHS
1 CN101,
60 430631080130R WAFER 2x4P 2.0mm,200PHD-2*4ST RoHS 1 CN105,
70 432008010370R XTAL 14.31818MHz 16pF HC-49US 30PPM,DIP,85
℃,RoHS
1 X101,
80 440819015030R CON,D-SUB,FEM.15P RA W/O SCREW DZ11AA1-H 1 CN103,
ITEM P/N Description Usage Location
790621340600R PCBA,IF BOARD,SMD, LE1730-6E0
10 410500045140R XSTR MMBT3904LT1G NPN 200MA 40V SOT23(ON 0
10 410500045130R XSTR MMBT3904 NPN SOT-23(INFIN EON)RoHS 0
10 410500045210R XSTR PMBT3904 NPN 200MA,40V SOT23(PHILIP 2 Q103,Q106,
20 410500046180R XSTR MMBT3906LT1G PNP 200mA 40V SOT23(ON 0
20 410500046130R XSTR MMBT3906 PNP SOT-23(INFIN EON)RoHS 0
20 410500046210R XSTR PMBT3906 PNP 200MA,40V SOT23(PHILIP 2 Q102,Q105,
30 410500044270R XSTR AO3401L P-CH(ALPHA-OMEGA) SOT23 RoH 0
30 410500068290R XSTR AP2305GN P-CH SOT23(APEC) RoHS 1 Q101,
40 410500050130R XSTR SN7002N N-CH SOT-23(INFINEON),RoHS 0
40 410500050210R XSTR 2N7002,N-CH FET SOT-23 (PHILIPS)RoH 1 Q107,
50 411020026020R DIO BAV99-LF 350mW 70V SOT-23 (FEC)RoHS 0
50 411020026390R DIO BAV99,SOT-23(INFINEON)RoHS 0
50 411020026210R DIO BAV99 350mW 70V SOT-23(PHI RoHS 4 TVS101,TVS102,TVS103,
TVS104,
60 411020047020R DIO BAV70-LF 70V SOT23 (FEC) RoHS 0
60 411020047210R DIO BAV70 85V SOT23 (PHILIPS) RoHS 1 D103,
70 411101156950R ZENER BZV55-C5V6 SOD80C(PHILIP S) RoHS 0
