27
360 444099030030R CON, SMD 1.0mm 30PIN RoHS AL2309-A0G1Z 1 CN104,
370 506140005700R LABEL,BARCODE,BLANK,33x7mm, ROHS,FOR PCB 1
380 490621300100R PCB,INTERFACE, LE1730-XE0 1
390 414916022150R
RES SMD (0603) 220Ω J,RT RoHS REV:A
1 R107,
400 414916560910R
RES SMD (0603) 56
Ω
F,RT RoHS REV:A
3 R113,R116,R119,
410 432002360140R
BEAD CORE SMD(0603)60
Ω
600mA, GBK160808
3 FB107,FB108,FB109,
PI BOARD
ITEM P/N Description Usage Location
790621400600R PCBA,PWR&INV./B, LE1730-6E0
10 412140001390R IC EL817M-B(EVERLIGHT)RoHS 0
10 412140002380R IC LTV817M-PR VDE (LITE-ON) P=10mm RoHS 1 IC801,
20 411050006041R DIO BRDG KBL06M 600V/4A(MOSPEC RoHS 0
20 411050007010R DIO BRDG KBL405G 600V/4A(TSC) RoHS 0
20 411050005020R DIO BRDG BL4-06-BF52-LF 600V/4A(FRONTIER 1 D801,
30 416194743011R CAP MEX 0.47uF 275V K X2,F15 RoHS 1 C804,
40 416202224610R CAP MEY 2200pF 400V M Y,F10mm RoHS 1 C820,
50 416202224610R CAP MEY 2200pF 400V M Y,F10mm RoHS 2 C801,C806,
60 420421020102R
CAP EC 1000uF/10V M,105℃ N-F 10x16(L-ES
2 C812,C809,
70 420421020211R
CAP SD 1000uF 25V M,105
℃
F 13x20 RoHS
1 C808,
80 420431014582R
CAP SEK 100uF/450V M,105℃ CF,18x35,RoHS
1 C805,
90 416204724610R CAP MEY 4700pF 400V M Y,F10mm RoHS 1 C824,
100 425000010530R COIL CHK 5uH 7.8X10 CHK-053 0 181085R0L 2 L802,L803,
110 426000050070R CHOKE L-FILTER 12mH LIN-007 ET-20,RoHS 1 L801,
120 426000090470R XFMR 750u@1K,+-8%,3m,113m,SPW- 047,DIP-1 1 T801,
130 432009400701R
NTC 5
Ω
4A 10
ψ
P=5mm, F RoHS
1 RT801,
140 430613125210R FUSE SLOW 2.5A/250V,U/C/V,AT,3.6x10,RoHS 1 F801,
150 440149000220R SKT AC 10A/250V U/C/V,G/Y=45mm TU-301-SP 1 P801,
160 430300600120R HRN ASS'Y 6P 110mm UL1007#24,RoHS 1 CN801,
180 418247233020R CAP CD X7R 4700pF 1KV K,W/O FO RMING,RoH 1 C803,
190 430637020020R
WFR. 2P P=3.5mm 90°4100-D02 RoHS
4 CN501,CN502,CN503,CN
504,
200 426000090670R XFMR SW,105uH EEL19M DIP SPW-067,RoHS 2 T501,T502,
210 418105058010R CAP CD SL 5pF 3KV K,F7.5 RoHS 2 C525,C527,
220 418110058510R CAP CD SL 10pF 3KV J,F7.5 RoHS CC45SL3FD 2 C524,C526,
230 410050062330R XSTR AF4971NN N-CH PDIP8(ANACH IP)RoHS 0
230 410500071290R XSTR AP9971GD,N-CH,PDIP-8(APEC RoHS 2 U501,U502,
240 735100007400R ASSY,H/S,UFF80-005CT/UFF80-015CT,LE1730 1
250 735100005100R ASSY,H/S TOP245Y, LE1704/05 ROHS 1
260 790621440600R PCBA,PWR&INV./B,SMD,LE1730-6E0 1
270 502040604500R SHIELD,EMI, LE1915 ROHS 1 H501,
280 511130001200R SOLDER BAR,Sn96.5/Ag3.0/Cu0.5/Ni0.06/Ge0 4.4965
290 511130000300R SOLDER WIRE,Sn96.5/Ag3.0/Cu0.5/Ni0.06/Ge 0.897
300 511110000101R HOT-MELT ADHESIVES (#526) 4.37115
310 511140000701R
FLUX Grade 0.812±0.010
3.7375
ITEM P/N Description Usage Location
735100005100R ASSY,H/S TOP245Y, LE1704/05 ROHS
10 412000342270R IC TOP245YN,TO-220-7C,RoHS (POWER INTEGR 1 IC802,
20 507200003700R HEATSINK,46x20xt10mm LE1704/05 1
To Next Page
