52 Multi Type Air Conditioner
6. To remove the Cross-Flow Fan
• Loosen the screw securing the cross-flow fan to
the fan motor (do not remove).
• Lift up the right side of the cross-flow fan and the
fan motor, separate the fan motor from the cross-
flow fan.
• Remove the left end of the cross-flow fan from
the self-aligning bearing.
To Next Page
