54 Multi Type Air Conditioner
Exploded View & Replacement Parts List
PART No.
LMNC122LRL0 LMNH122LRA0 LMNC122LRL0 LMNC122LRA0 L3NC122NRA1
131410 CHASSIS ASSEMBLY 3141A20005B 3141A20005B 3141A20005B 3141A20005B 3141A20005G R
135311 GRILLE ASSEMBLY,DISCHARGE(INDOOR) 5231A10230A 5231A10230A 5231A10230A 5231A10230A 5231A10230W R
152313 FILTER ASSEMBLY, DEODORIZER 5231A20032C 5231A20032E 5231A20032C 5231A20032E - R
135314 GRILLE ASSEMBLY,INLET SUB 3531A10117B 3531A10117B 3531A10283D 3531A10283D - R
135316 GRILLE ASSEMBLY,FRONT(INDOOR) 3531A20107F 3531A10208X 3531A10208W 3531A21017G 3531A21016F R
135516 COVER ASSEMBLY,MOTOR 3551A20099A 3551A20099A 3551A20099A 3551A20099A 3551A20099A R
146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A 4681A20055A 4681A20055A 4681A20055A R
152302 FILTER(MECH),A/C 5230A20014C 5230A20014C 5230A20014C 5230A20014C 5230A20014C R
159830 AIR CLEANER ASSEMBLY 5983A10006U 5983A10006U 5983A10006U 5983A10006U - R
159901 VANE,HORIZONTAL 5990A20007A 5990A20007A 5990A20007A 5990A20007A 5990A20007B R
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A10072G 4995A20361Y 4995A20361V 4995A10072E 4995A10072E R
263230-1 THERMISTOR ASSEMBLY 6323AQ3226T 6323AQ3226T 6323AQ3226T 6323AQ3226T 6323AQ3123A R
263230-2 THERMISTOR ASSEMBLY 6323A20004A 6323A20004A 6323A20004A 6323A20004A 6323A20004A R
266090 H.V ASSEMBLY 6609A10003H 6609A10003H 6609A10003H 6609A10003H - R
267110 REMOTE CONTROLLER ASSEMBLY 6711A20073F 6711A20073N 6711A20073M 6711A20073L 6711A20025U R
268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A20390A 6871A20390A 6871A20390A 6871A20390A 6871A20390A R
268715 PWB(PCB) ASSEMBLY,MAIN(AC) 6871A20267B 6871A20267B 6871A20267B 6871A20267B 6871A20267B R
268716 PWB(PCB) ASSEMBLY,MAIN(DC) 6871A20440N 6871A20440N 6871A20440P 6871A20440P 6871A20440P R
342800 BEARING 4280A20004A 4280A20004A 4280A20004A 4280A20004A 4280A20004A R
346810 MOTOR ASSEMBLY,INDOOR 4681A20048D 4681A20048D 4681A20048D 4681A20048D 4681A20048D R
352115 TUBE ASSEMBLY,EVAPORATOR IN 5211A20038H 5211A20038H 5211A20038H 5211A20038H 5211A20388H R
352116 TUBE ASSEMBLY,EVAPORATOR OUT 5211A20389F 5211A20389F 5211A20389F 5211A20389F 5211A20389F R
352150 HOSE ASSEMBLY,DRAIN 5251AR2575F 5251AR2575F 5251AR2575F 5251AR2575F 5251AR2575F R
354210 EVAPORATOR ASSEMBLY, FIRST 5421A20086A 5421A20086A 5421A20086A 5421A20086A 5421A20086A R
359011 FAN ASSEMBLY,CROSS FLOW 5901A20007A 5901A20007A 5901A20007A 5901A20007A 5901A20007A R
733010 PLATE ASSEMBLY,INSTALL 1H00843A 1H00843A 1H00843A 1H00843A 1H00843A R
W0CZZ CAPACITOR,DRAWING 3H01487A 3H01487A 3H01487A 3H01487A 3H01487A R
DESCRIPTION
SVC
CODE
LOCATION
No.
To Next Page
