LG L3UC482FA0 - Page 57

Service Manual 57
PART No.
LMNH242TL0 LMNH242LTA0 LMNC242LTL0 LMNC242LTA0 L3NC242NRA1
131410 CHASSIS ASSEMBLY 3141A10002B 3141A10002B 3141A10002B 3141A10002B 3141A10002H R
135311 GRILLE ASSEMBLY,DISCHARGE(INDOOR) 3531A10116A 3531A10116A 3531A10116A 3531A10116A 3531A10224A R
135316 GRILLE ASSEMBLY,FRONT(INDOOR) 3531A24010D 3531A20207L 3531A20207K 3531A24010E 3531A21020G R
135516 COVER ASSEMBLY,MOTOR 3551A20099C 3551A20099C 3551A20099C 3551A20099C 3551A20099C R
146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A 4681A20055A 4681A20055A 4681A20055A R
152302 FILTER(MECH),A/C 5230A20001A 5230A20001A 5230A20001A 5230A20001A 5230A20001A R
152131 FILTER ASSEMBLY, DEODORIEER - 5231A20032F - 5231A20032F - R
159830 AIR CLEANER ASSEMBLY 5983A10006U - 5983A10006T - - R
159901-1 VANE,HORIZONTAL 5990A20008A 5990A20008A 5990A20008A 5990A20008A 5990A20008B R
159901-2 VANE,HORIZONTAL 5990A20009A 5990A20009A 5990A20009A 5990A20009A 5990A20009B R
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A10072H 4995A20361X 4995A20361W 4995A10072F 4995A10072F R
263230-1 THERMISTOR ASSEMBLY 6323AQ3226T 6323AQ3226T 6323AQ3226T 6323AQ3226T 6323AQ3226T R
263230-2 THERMISTOR ASSEMBLY 6323A20004A 6323A20004A 6323A20004A 6323A20004A 6323A20004A R
266090 H.V ASSEMBLY 6609A10003L - 6609A10003L - - R
267110 REMOTE CONTROLLER ASSEMBLY 6711A20073F 6711A20073N 6711A20073M 6711A20073L 6711A20025U R
268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A20194B 6871A20194B 6871A20194B 6871A20194B 6871A20194B R
268715 PWB(PCB) ASSEMBLY,MAIN(AC) 6871A20267B 6871A20267B 6871A20267B 6871A20267B 6871A20267B R
268716 PWB(PCB) ASSEMBLY,MAIN(DC) 6871A20440Q 6871A20440Q 6871A20440R 6871A20440R 6871A20440R R
342800 BEARING 4280A20004A 4280A20004A 4280A20004A 4280A20004A 4280A20004A R
346810 MOTOR ASSEMBLY,INDOOR 4681A20003F 4681A20003F 4681A20003F 4681A20003F 4681A20003F R
35211B TUBE ASSEMBLY,TUBING 5211AR7066U 5211AR7066U 5211AR7066U 5211AR7066U 5211AR7066U R
352115 TUBE ASSEMBLY,EVAPORATOR IN 5211A30058H 5211A30058H 5211A30097J 5211A30097J 5211A30058H R
352116 TUBE ASSEMBLY,EVAPORATOR OUT 5211A30057D 5211A30057D 5211A30098G 5211A30098G 5211A30057D R
352150 HOSE ASSEMBLY,DRAIN 5251AR2575F 5251AR2575F 5251AR2575F 5251AR2575F 5251AR2575F R
359011 FAN ASSEMBLY,CROSS FLOW 5901A20008A 5901A20008B 5901A20008A 5901A20008A 5901A20008A R
733010 PLATE ASSEMBLY,INSTALL 3301A10002A 3301A10002A 3301A10002A 3301A10002A 3301A10002A R
W0CZZ CAPACITOR,DRAWING 3H01487G 3H01487G 3H01487G 3H01487G 3H01487G R
W51620 SOCKET(MECH), FLARE 5162A20011A 5162A20011A 5162A20011A 5162A20011A 5162A20011A R
DESCRIPTION
SVC
CODE
LOCATION
No.
