LG L3UC482FA0 - Page 59

Service Manual 59
Exploded View & Replacement Parts List
PART No.
LMNH126BTG0 LMNH186BTG0
152302 FILTER(MECH), A/C 5230A30001Q 5230A30001P R
237203 PANEL ASSEMBLY, UPPER 3721A20150B 3721A20150A R
249951 CONTROL BOX ASSEMBLY(INDOOR) 4995A20338E 4995A20338J R
263230-1 THERMISTOR ASSEMBLY (IN) 6323AQ3226G 6323AQ3226G R
263230-2 THERMISTOR ASSEMBLY (ROOM) 6323AQ3214E 6323AQ3214E R
263230-3 THERMISTOR ASSEMBLY (OUT) 6323A20025D 6323A20025D R
267110 REMOTE CONTROLLER ASSEMBLY 6711A10008U 6711A10008U R
268714 PWB(PCB) ASSEMBLY, MAIN 6871A10131B 6871A10131G R
330860 DRAIN PAN ASSEMBLY 3087A10015C 3087A10015B R
336610 HOUSING(MECH), WRAPPER 3660A20033A 3660A20033A R
346810 MOTOR ASSEMBLY, INDOOR 4681A10022B 4681A10022A R
352118 TUBE ASSEMBLY, MENIFOLD(INDOOR) 5211A25011B 5211A10418C R
354210 EVAPORATOR ASSEMBLY, FIRST 5421A21002A 5421A20153A R
359012-1 FAN ASSEMBLY, BLOWER(Single) 5901A20030A 5901A20030A R
359012-2 FAN ASSEMBLY, BLOWER(Single) - 5901A20030B R
352111 TUBE ASSEMBLY, CONNECTOR - 5211A20514G R
552111 TUBE ASSEMBLY, EVAPORATOR IN 5211A25010A 5211A10417B R
WOCZZ CAPACITOR, DRAWING 3A02157K 3A02157H R
DESCRIPTION
SVC
CODE
LOCATION
No.
