LG L3UC482FA0 - Page 61

Service Manual 61
Exploded View & Replacement Parts List
PART No.
LMNH242BHA0 LMNC242BHA0
152302 FILTER (MECH), A/C 5230A30001M 5230A30001A R
237210 PANEL ASSEMBLY, UPPER 3721A20177A 3721A20184A R
249951 CONTROL BOX ASSEMBLY(INDOOR) 4995A14002B 4995A20011B R
263230-1 THERMISTOR ASSEMBLY(IN) 6323AQ3226G 6323AQ3226G R
263230-2 THERMISTOR ASSEMBLY(ROOM) 6323AQ3214E 6323AQ3214Q R
263230-3 THERMISTOR ASSEMBLY (OUT) 6323AQ3226V 6323AQ3226V R
267110 REMOTE CONTROLLER ASSEMBLY 6711A10008X 6711A10008X R
268714 PWB(PCB) ASSEMBLY, MAIN 6871A10140F 6871A10040M R
330860 DRAIN PAN ASSEMBLY 3087A10008B 3087A20023A R
336610-1 HOUSING(MECH), WRAPPER 3660A20017A 3660A20008C R
336610-2 HOUSING(MECH), WRAPPER 3660A20018A 3660A20010B R
346810 MOTOR ASSEMBLY, INDOOR 4681A10013C 4681A20005Y R
352111* TUBE ASSEMLBY, CONNECTOR 5211A20514G 5211A20514J R
352118 TUBE ASSEMBLY, MENIFOLD(INDOOR) 5211A20465G 5211A30076A R
354210 EVAPORATOR ASSEMBLY, FIRST 5421A20100B 5421A20008A R
359012-1 FAN ASSEMBLY, BLOWER(Single) 5901A10026A 5901A10026A R
359012 FAN ASSEMBLY, BLOWER(Motor) 5901A10028B 5901A10028A R
552111 TUBE ASSEMBLY, CAPILLARY 5211A20466L 5211A20693D R
WOCZZ CAPACITOR, DRAWING 2A00986D 2A00986D R
DESCRIPTION
SVC
CODE
LOCATION
No.
