Service Manual 63
Exploded View & Replacement Parts List
131410 CHASSIS ASSEMBLY 3141A20007B R
135080 DECORATION (TOP) 3508A20034A R
135080 DECORATION (BOTTOM) 3508A20034B R
135311 GRILLE ASSEMBLY, DISCHARGE 3531A10137E R
135314 GRILLE ASSEMBLY, INLET MIRROR 3531A20118E R
BLUE 3531A20138X R
WHITE 3531A20138W R
METAL 3531A20138Y R
CHERRY 3531A20138Z R
135312 GRILLE ASSEMBLY, FRONT MIRROR 3531A10147H R
BLUE 3531A10158Q R
WHITE 3531A10158P R
METAL 3531A10158R R
CHERRY 3531A10158S R
145200 LINK 4520A20008A R
146811 MOTOR ASSEMBLY, STEP 4681A20055A R
146811 MOTOR ASSEMBLY, STEP 4681A20055B R
152302 FILTER (MECH), A/C 5230A20022A R
159901 VANE HORIZONTAL 5990A20015B R
249951 CONTROL BOX ASSEMBLY 4995A10138A R
268712 DISPLAY LED ASSEMBLY 6302A90003A R
263230 THERMISTOR ASSEMBLY 6323A20004H R
264110 POWER CORD ASSEMBLY 6411A20026J R
266090 H.V ASSEMBLY 6609A10005A R
267110 REMOTE CONTROLLER ASSEMBLY 6711A20083Q R
268714 PWB(PCB) ASSEMBLY, MAIN 6871A20522A R
342800 BEARING 4280A20004A R
346810 MOTOR ASSEMBLY, INDOOR 4681AR2295K R
35211B TUBE ASSEMBLY, TUBING 5211AR7066N R
352150 HOSE ASSEMBLY, DRAIN 5251AR1222R R
354212 EVAPORATOR ASSEMBLY, FINAL 5421A20150A R
359011 FAN ASSEMBLY, CROSS FLOW 5901A20016A R
668713 PWB ASSEMBLY, SUB 6871A20258B R
668713 PWB ASSEMBLY, SUB 6871A20259A R
73310 PLATE 1H00843A R
W0CZZ CAPACITOR,DRAWING - R
LOCATION
No.
DESCRIPTION
PART No.
LA140CE
REMARKS
Parts List(Indoor)
To Next Page
