Service Manual 65
Exploded View & Replacement Parts List
430410 BASE ASSEMBLY, OUTDOOR 3041A20008J R
435511 COVER ASSEMBLY, CONTROL 3551AR7184R R
437210 PANEL ASSEMBLY, FRONT 3721A20027B R
437212 PANEL ASSEMBLY REAR 3721A20026A R
447910 BARRIER ASSEMBLY, OUTDOOR 4791A30002A R
546810 MOTOR ASSEMBLY, OUTDOOR 4681A20004R R
550140 ISOLATOR, COMP. 4H00982E R
552102-1 TUBE, CAPILLARY BENT - R
552102-2 TUBE, CAPILLARY BENT 5210A21147B R
552111 TUBE ASSEMBLY, CAPILLARY 5211A21143H R
552116 TUBE ASSEMBLY, REVERSING - R
552201 VALVE, CHECK - R
552202 VALVE, REVERSING - R
552203-1 VALVE, SERVICE 5220A20005B R
552203-2 VALVE, SERVICE 5220A20003B R
554031 CONDENSER ASSEMBLY, BENT 5403A20026K R
554160 COMPRESSOR 2520UKJC2AA R
559010 FAN ASSEMBLY, PROPELLER 5901A10004A R
W0CZZ CAPACITOR, DRAWING 0CZZA20001L R
435301 GRILLE, DISCHARGE 3530A20006B R
561410 COIL ASSEMBLY, REVERSING VALVE - R
649950 CONTROL BOX ASSEMBLY, OUTDOOR 4995A20083W R
LOCATION
No.
DESCRIPTION
PART No.
LA140CE
REMARKS
Parts List(Outdoor)
