18
Specications
Wireless module specifications
• As band channels can vary per country, the user cannot change or
adjust the operating frequency. This product is congured for the
regional frequency table.
• For consideration of the user, this device should be installed and
operated with a minimum distance of 20 cm between the device
and the body.
(Only LF63**, LF65**)
Wireless module (LGSBW41) Specifications
Wireless LAN (IEEE 802.11a/b/g/n)
Frequency range Output power(Max.)
2400 to 2483.5 MHz
5150 to 5250 MHz
5725 to 5850 MHz (Not for EU)
16 dBm
16 dBm
11.5 dBm
Bluetooth
Frequency range Output power(Max.)
2400 to 2483.5 MHz 10 dBm
(Only LH56**, LF59**)
Wireless LAN module(TWFM-B006D) specification
Standard IEEE802.11a/b/g/n
Frequency range Output power(Max.)
2400 to 2483.5 MHz
5150 to 5250 MHz
5725 to 5850 MHz (for Non EU)
14 dBm
12.5 dBm
15.5 dBm
To Next Page
