16 INSTALLATION
• Place the door, inside facing up, on a
nonscratching surface.
Removing the Right Refrigerator
Door
1 Remove the screw a from the hinge cover at
the top of the refrigerator. Lift the hook (not
visible), located at the bottom of the front side
of the cover
b with a flat-head screwdriver.
2 Remove the three bolts using a 13/32 in. (10
mm) socket wrench and lift off the top hinge.
Set parts aside.
• When lifting the hinge free of the latch, be
careful that the door does not fall forward.
3 Lift the door from the middle hinge pin and
remove the door.
• Place the door, inside facing up, on a
nonscratching surface.
Removing Freezer Drawers
This feature is only available on some models.
• To prevent accidents, keep children and pets
away from the drawer. Do not leave the drawer
open. If the Durabase storage bin is removed
from the freezer drawer, there is sufficient space
for a small child or pet to crawl inside.
• Do not sit or stand on the freezer drawer.
• Use two or more people to remove and install
refrigerator doors and freezer drawers.
• Be careful of sharp hinges on both sides of the
drawer.
• When you lay the drawer down, be careful not to
damage the floor.
1 Pull the drawer open to full extension.
2 Gently lift and pull out the ice bin.
