18 INSTALLATION
2 Grasp the drawer on each side and hook the
drawer supports into the rail tabs located on
both sides.
• Do not hold the handle when removing or
replacing the drawer. The handle may come off,
causing personal injury.
3 Lower the door into its final position and
insert the screws in the rails on both sides.
4 Insert the Durabase basket in the rail
assembly.
5 Insert the drawer into the frame, and push
the drawer back until it clicks into place.
Replace the ice bin in the drawer.
Assembling the Right Refrigerator
Door
• Install the right-side door first.
1 Make sure that the hinge pin sleeve is
inserted in the bottom of the door. Lower the
door onto the middle hinge pin.
2 Align the door with the cabinet.
3 Line up the top hinge with the holes in the top
of the refrigerator. Use the three bolts to
replace the hinge. Tighten the bolts.
4 Replace the hinge cover a. Insert and tighten
the cover screws b.
