LG LFCS31626 Series User Manual

- 10 -
3-8 HOW TO REMOVE AND REINSTALL THE PULLOUT DRAWER
3-8-1 Follow Steps to Remove
Step 1) Open the freezer door.
Step 3) Remove the two screws from the guide rails (one
from each side).
Step 2) Remove the lower basket.
Step 4) Removal of the freezer door is done by l ifting clear
of the rail support.
Fully extend both rails.
Step 5) Remove only 1 screw of gearice, and disassemble
the bar and gearice
Step 6) Remove 2 screws of both side of supporter covers
tv and disassemble the supporter cover tv.

LG LFCS31626 Series Specifications

General

Color	stainless steel
Refrigerator Capacity	30.6 cubic feet
Freezer Capacity	10.1 cubic feet
Humidity Controlled Crispers	no
Number of Refrigerator Door Bins	yes
Temperature Control	digital
Interior Light	led
Ice Maker	yes
Door Alarm	yes
Annual Energy Consumption	674 kilowatt hours
Current	20 amperes

Weight and Dimensions

Depth	36.25 inches
