3.6 GPS Trouble shooting
3.6.1 GPS IC Component
Reference No. Description Reference No. Description
FL2011 SAW Filter U2005 GPS LNA
FL2009 GPS & B7/41 Diplexer SW2001 RF SWITCH
ANT2003 GPS ANT (Signal) U2004 WTR1605L
ANT2002 GPS ANT (GND)
U2004
BOT
