2. PERFORMANCE
- 6 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D821 Product SPEC
5
2.3 Main Parts & Solution
Item Part Name Comment
Digital Baseband AP Q8064 : Qualcomm
Analog Baseband MDM9215M : Qualcomm
RF Chip WTR1605L : Qualcomm
2.4 HW Features
Item Feature Comment
Form Factor DOP type
Battery
1) Capacity
Standard : Li-Ion Polymer, 2300mAh
2) Packing Type : Soft Pack Embeded
Size
Standard :
133.9 x 68.7 x 9.1 (unit : mm)
Weight 139.5 g with Battery
PCB FR4, 10 Layers , 0.8t
Stand by time
CDMA Up to 350 hrs
GSM Up to 350 hrs
WCDMA Up to 350 hrs
LTE Up to 350 hrs
@ SCI2 (CDMA)
@ Paging Period 5 (GSM)
@ DRX 7 (WCDMA)
@ DRX7 (LTE)
Charging time 3 hrs 30min @ Power Off
Talk time
CDMA Up to 690 min
GSM Up to 405 min
WCDMA Up to 530min
LTE Up to 230 min
@ Tx= 10dBm (CDMA)
@ TX=LV5(EGSM)
@ Tx = 10dBm (WCDMA)
@ Tx = 10dBm (LTE )
RX sensitivity
WCDMA(FDD1) : -108 dBm
WCDMA(FDD2) : -108 dBm
WCDMA(FDD2) : -108 dBm
WCDMA(FDD5) : -108 dBm
WCDMA(FDD8) : -108 dBm
EGSM : -108 dBm
GSM850 : -108 dBm
DCS 1800 : -108 dBm
