3. TROUBLE SHOOTING
- 170 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
< Barometer Sensor >
< Main board _Bottom >
U11003 (BMP280)
Barometer Sensor
EAN62695801
U11003
BMP280
8
4
3
7
5
6
2
1
GND1
CSB
VDDIO
SDO
GND2
SDI
SCK
VDD
+3V0_VREG_L17
+1V8_VREG_LVS1
0.1u
C11001
C11002
0.1u
COMPASS_OUT_I2C_SDA
COMPASS_OUT_I2C_SCL
U11003
