2. PERFORMANCE
- 25 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D821 Product SPEC
24
Intermodulation
Performance
DH1
PRBS9
Δf = +5MHz (CW)
Δf = +10MHz (BT)
BER @ 0.1%
- -64 dBm
Δf = -5MHz (CW)
Δf = -10MHz (BT)
BER @ 0.1%
- -64 dBm
Maximum Input Level
DH1
PRBS9
BER @ 0.1% -20 -
dBm
12) GPS receiver specification
Item Specification
Receive Frequency 1574.42 MHz ~ 1576.42 MHz
Minimum Sensitivity 1 satellite ≥-142dBm, 7 satellites ≥ -147dBm at coarse time aiding
13) NFC
Operate below 3 mode.
1) Card mode : Smart Card capability for mobile device(recognition distance : over 20mm)
2) Reader mode : Get information from tag(recognition distance : over 20mm)
3) Peer-to-peer mode : Device to device communication(recognition distance : over 5mm)
LG-D821 Product SPEC
24
Intermodulation
Performance
DH1
PRBS9
Δf = +5MHz (CW)
Δf = +10MHz (BT)
BER @ 0.1%
- -64 dBm
Δf = -5MHz (CW)
Δf = -10MHz (BT)
BER @ 0.1%
- -64 dBm
Maximum Input Level
DH1
PRBS9
BER @ 0.1% -20 -
dBm
12) GPS receiver specification
Item Specification
Receive Frequency 1574.42 MHz ~ 1576.42 MHz
Minimum Sensitivity 1 satellite ≥-142dBm, 7 satellites ≥ -147dBm at coarse time aiding
13) NFC
Operate below 3 mode.
1) Card mode : Smart Card capability for mobile device(recognition distance : over 20mm)
2) Reader mode : Get information from tag(recognition distance : over 20mm)
3) Peer-to-peer mode : Device to device communication(recognition distance : over 5mm)
13) GPS receiver specication
14) NFC
Operate below 3 mode.
1) Card mode : Smart Card capability for mobile device(recognition distance : over 20mm)
2) Reader mode : Get information from tag(recognition distance : over 20mm)
3) Peer-to-peer mode : Device to device communication(recognition distance : over 5mm)
