3. TROUBLE SHOOTING
- 42 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Check TP1
TP1 > 2.95V
Check the Power ON
No
Yes
Check TP2
TP2 > 1.8V
TP3 Signal?
Check the PM8941
Check the FL1018
Check the U1000
No
No
Yes
Yes
Check TP3
RF Path Open
