3. TROUBLE SHOOTING
- 88 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Check TP1
Check TP1
Signal Exist?
Check the RX Level
Yes
Yes
Yes
No
No
No
Check the U2004
(WTR1605L-1)
Check TP2
Signal Exist?
Check the U1000
Check TP3
Signal Exist?
Check the FL1003
(B8 Duplexer)
SAYFH897MHE0F0A
FL1003
EAM62514001
75
8
4 9
2
3
16
ANT RX1
TX
GND1
GND5GND2
RX2
GND3 GND4
18nC1027
C1026 33p
6.2n
L1017
C1019 18n
L1011
DNI
PRX_LB2_IN_N
PRX_LB2_IN_P
TX_PA_OUT_B8
TRX_B8
B8/G900
TP3
TP2
