4. TROUBLE SHOOTING
- 113 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
4.6.8 Checking RF DRX Level [UMTS Band5]
Test Point (UMTS Band5 RF PRX Level)
Schematic of LTE Band5 RF DRX Level.
FL1201
881.5 MHz
52
3
4
1
IN
OUT_
OUT
G1 G3
L1205
100p
100n
L1215
L1217 12n
12nL1213
C1220100p
L1214
18n
L1216
DNI
100pC1219100pC1276
L1270
DNI
100n
L1271
ANT1200
MCE62492901
FEED
ANTENNA
ANT1201
MCE62492901
FEED
ANTENNA
DRX_L20_INM
DRX_L20_INP
ANT3 U850 DRX
TP1
TP2
TP1
TP2
