4.21 NFC Troubleshooting
Check out the setting menu on the phone. If not, check Test points shown on the pictures.
Check Ref ClKsignal
XTAL_XOP/XON (Pin26)
Check 2.5V-5.5V to
VBATT(Pin26)
Check VDDIO (Pin13)&
Drive REG_PU (Pin25) to VDDIO?
Check VDD_EN(Pin32) 1.8V min?
START
Re-download SW or
BCM20793 chip FW update
Check Coupled Tx signal
Check NFC Antenna
