4. TROUBLE SHOOTING
- 116 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
4.7.2 WIFI,BT Module
LBDA525WVZ-575 is the combination module that integrates WLAN(WIFI) and BT (built-in clock and BPS lter, diplexer
etc. )
Reference Description
ANT9001
C-Clip
Connected to antenna
ANT9002
C-Clip
Connected to antenna
U9001 BT,WIFI Module
ANT9002
ANT9001
U9001
BT,WIFI Module
