4. TROUBLE SHOOTING
- 145 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Gyro sensor
U8002
22
19
20
21
23
24
18 17
9
8
10
7
11
6
12
5
13
4
14
3
15
2
16
1
CLKIN
NC7
NC1
NC6
NC2
NC5
NC3
VDD
NC4
INT
AUX_DA
FSYNC
AUX_CL
REGOUT
VLOGIC
AD0
NC8
GND
SDA
SCL
RESV2
CPOUT
RESV1
CLKOUT
C8002
10n
C8006
0.1u
C8003 0.1u
2.2n
C8004
I2C_SENSOR_SDA
I2C_SENSOR_SCL
VREG_LVS4_1P8
GYRO_INT
VREG_L9_3P0
Rev.B
Rev.B
Rev.B
Gyro sensor
