4. TROUBLE SHOOTING
- 154 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Mainboard bottom(Pressure Sensor)
C8007
0.1u
0.1u
C8008
U8003
BMP180
BOSCH
EAN62239601
4
3
7
5
6
2
1
CSB
VDD
SDA
SCL
GND
VDDIO
SDO
I2C_SENSOR_SDA
I2C_SENSOR_SCL
VREG_LVS4_1P8VREG_L9_3P0
TP2
TP1
Pressure Sensor
