4. TROUBLE SHOOTING
- 163 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
4.18.5 Checking NFC Antenna (Battery Cover)
Doing visual inspection.
4.21.5 Checking NFC Antenna (Battery Cover)
Doing visual inspection.
START
Antenna OK?
Replace
Antenna
No
Yes
Re-download SW or
BCM20793 chip FW update
Checking the Soldering as belows:
4.18.5 Checking NFC Antenna (Battery Cover)
Doing visual inspection.
Battery cover
