12. EXPLODED VIEW & REPLACEMENT PART LIST
- 282 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6 PT1101 Thermistor,NTC SETY0006301
NCP15XH103J03RC 10KOHM 5% 0V 0A 3.35KK
SMD P/TP 1005size MURATA MANUFACTURING
CO.,LTD.
6 C11031
Inductor
Multilayer,Chip
ELCH0003844
LQG15HS2N0S02D 2NH 0.3NH - 300mA 0.1OHM
6GHZ 8 SHIELD NONE 1.0X0.5X0.5MM R/TP
MURATA MANUFACTURING CO.,LTD.
6
R1102
R1103
R13002
R14006
R14007
R15005
R21015
R22001
R23011
R23017
R23019
R23021
R5001
R5002
R5003
R5004
R6030
R7017
R9008
R9009
PCB ASSY
MAIN
PAD SHORT
SAFP0000401 LG-LU3000 LGTBK,MAIN,A,
6
R200
R201
R202
Resistor,Chip ERHY0009501
MCR006YZPJ000 0OHM 5% 1/20W 0603 R/TP -
ROHM.
6
C15025
C15026
C15027
C15028
C15029
C23013
C6018
C7021
C7022
C9038
Capacitor
Ceramic,Chip
EAE62502901
CL05A106MP5NUNC 10uF 20% 10V X5R -
55TO+85C 1005 R/TP 0.55T max. SAMSUNG
ELECTRO-MECHANICS CO., LTD.
