4. TROUBLE SHOOTING
- 70 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
U11004Part Name=ACPM-5702-TR1
Vendor=AVAGO
6
7 4
8 3
5
9 2
10 1
11
PGND
VCC1VCC2
RFINRFOUT
VEN
NCISO
VMODEGND
CPL
C11059
DNI
330p
C11044
C11045
4.7u
L11039 100p
C11058
3.9n
PA_DET_MMMB +VSMPS
TX_ANT_LU1900
PA_DET_1
UMTS_L2 TX
L11041 2.2n
DNI
L11044
C11057 33p33pC11056
4
3
5
2
1
NC
L11040 33p
L11045
6.8n
100pC11063
C11064 100p C11065 100p
330pC11046 4.7uC11047
1880MHz
Vendor=MURATA
Part Name=SAFEA1G88KB7F00
FL11006
5 2
4 1
3
G3
INOUT
G1G2
+VPWR
PA0_R1
PA0_R0
PA_ON4_U1900
TX_OUT_U1900
TP2
TP3
