2. PERFORMANCE
- 9 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
4) Battery Type
Li-ion Battery Pack, 2100 mAh
Standard Voltage : 3.7 V, Battery Full Charge Voltage : 4.1V ~ 4.25V
5) Current Consumption
Item WCDMA Only GSM Only Comment
Standby
9mA ↓ (DRX 7) 8.5mA(PP=5) ↓
GPS & Wifi Off
Neighborhood
Cell Off,
LCD Off
Talk Mode
- Max Pwr :
600mA↓ @ Avg
- Tx 10dBm :
400 mA↓ @ Avg 400mA(Tx Lvl: 5) ↓
GPS & Wifi Off
Neighborhood
Cell Off,
Power Off
300uA ↓ 300uA ↓
6) Battery Bar
Battery Bar Specification Battery Bar Specification
Bar 20(Full) 98% above Bar 9 -> Bar 8 43% -> 42%
Bar 20 -> Bar 19 98% -> 97% Bar 8 -> Bar 7 38% -> 37%
Bar 19 -> Bar 18 93% -> 92% Bar 7 -> Bar 6 33% -> 32%
Bar 18 -> Bar 17 88% -> 87% Bar 6 -> Bar 5 28% -> 27%
Bar 17 -> Bar 16 83% -> 82% Bar 5 -> Bar 4 23% -> 22%
Bar 16 -> Bar 15 78% -> 77% Bar 4 -> Bar 3 18% -> 17%
Bar 15 -> Bar 14 73% -> 72% Bar 3 -> Bar 2 13% -> 12%
Bar 14 -> Bar 13 68% -> 67% Bar 2 -> Bar 1 8% -> 7%
Bar 13 -> Bar 12 63% -> 62% Bar 1 -> Bar 0 3% -> 2%
Bar 12 -> Bar 11 58% -> 57% Power off 1% below
Bar 11 -> Bar 10 53% -> 52% Low battery pop-up 15% , 5%, 0%
Bar 10 -> Bar 9 48% -> 47%
Item WCDMA Only GSM Only Comment
Standby 9 mA ↓ (DRX7) 8.5 mA(PP=5) ↓
GSP & Wi O
Nelghborhood
Cell O,
LCD O
Talk Mode
- Max Pwr :
600 mA ↓ @ Avg
- Tx 10 dBm :
400 mA ↓ @ Avg
400 mA(Tx Lvl : 5 ) ↓
GSP & Wi O
Nelghborhood
Cell O
Power O 300 uA ↓ 300 uA ↓
4) Battery Type
Li-ion Battery Pack, 2100 mAh
Standard Voltage : 3.7 V, Battery Full Charge Voltage : 4.1V ~ 4.25V
5) Current Consumption
6) Battery Bar
