Preparing the Installation Area
INSTALLATION
23-1/16 inches ~ 26 inches (Ceiling Opening)
20-3/8 inches
18-5/32 inches
20-3/8 inches
23-1/16 inches ~ 26 inches (Ceiling Opening)
20-19/32 inches
22-15/32 inches
Unit Size
22-15/32 inches
Unit Size
12-9/16 inches
)RUHDVLHULQVWDOODWLRQDWWDFKWKHDFFHVVRULHVH[FHSWIRUWKHGHFRUDWLRQSDQHOEHIRUHKDQJLQJWKHLQGRRUXQLW
Figure 9: Cassette Indoor Unit Templates.
Level
Ceiling
Ceiling
Figure 10: Drilling Holes Using Template.
Figure 11: Ceiling Opening Dimensions and Bolt Locations.
Preparing the Installation Area
1. Cassette indoor units include installation guides (templates) that depict the exact dimensions necessary for the ceiling opening. One is
a paper template that is found in the cassette indoor unit shipping materials; the other template is the cardboard on the bottom of the
packaging.
2. Using one of the templates, choose the location for the indoor unit. Mark where the four (4) suspension / hanger bolts, refrigerant piping,
and drain hose should be. Suspension bolt angle must account for drain direction.
3. Drill holes for the four (4) suspension / hanger bolts.
WARNING
• 7KHWKUHDGHGURGKDQJDUVEROWVDQGKDUGZDUHPXVWEHVHFXUHO\
LQVWDOOHGWRSUHYHQWWKHIUDPHIDOOLQJIURPLWVORFDWLRQ7KHUHLVULVN
RISHUVRQQHOLQMXU\IURPIDOOLQJHTXLSPHQW
• 8VLQJWZRQXWVWRSUHYHQWVHOIORRVHQLQJLVKLJKO\UHFRPPHQGHG
7KHUHLVULVNRISHUVRQQHOLQMXU\IURPIDOOLQJHTXLSPHQW
• ,QVWDOODWLRQZRUNPXVWEHSHUIRUPHGE\WUDLQHGSHUVRQQHODQGLQ
DFFRUGDQFHZLWKDOOORFDORURWKHUDSSOLFDEOHFRGHV7KHUHLVULVNRI
SHUVRQQHOLQMXU\IURPLQFRUUHFWLQVWDOODWLRQ
• 'XULQJLQVWDOODWLRQ
GRQRWGDPDJHWKHFDEOHZLULQJ7KHUHLVD
ULVNRIHOHFWULFDOVKRFNILUHSK\VLFDOLQMXU\DQGRUGHDWK
