LG LMHM2017ST Service Manual

-22-
9
Is the resistance of the high
voltage capacitor out of
rage?
(Refer to 10)
Test Point
No
Yes
Replace the
high voltage
capacitor.
8
Is the connector connected
to High Voltage capacitor
assembly disconnected or
disassembled?
No
Yes
Reconnect or
repair the
connector.
10
Is the connector connected
to the high voltage diode
assembly disconnected or
disassembled?
No
Yes
Reconnect or
repair the
connector.
12
Is the connector connected
to magnetron assembly
disconnected or
disassembled?
Yes
11
Is the resistance of the high
voltage diode out of rage?
(Refer to 10)
Yes
No
Replace the
high voltage
Diode.
Forward
ForwardForward
Forward
Forward
Forward
Forward
Forward
Forward
Forward
Forward
Forward
Forward
Forward
Reconnect or repair the
connector.
