- 7 -
1. Remove gasket
Pull gasket free from gasket channel on the four
remaining sides of door.
3-2 DOOR
●
Mullion Removal
1. Remove 2 screws.
●
Door Gasket Removal
2. Lift Mullion up carefully.
3. Disconnect wire harness.
●
Door Gasket Replacement
1. Insert gasket into channel
Press gasket into channels on the four remaining
sides of door.
2. Insert mullion into the channel.
Insert the cover assembly into bracket, door.
●
Mullion Replacement
1. Connect wire harness.
3. Assemble 2 screws.
