PREPARE TO INSTALL THE RANGE
MINIMUM DIMENSIONS (Figure 2)
* 30" (76.2 cm) minimum clearance between the top of the cooking surface and the bottom of an unprotected wood
or metal cabinet; or 24" (60.9 cm) minimum when bottom of wood or metal cabinet is protected by not less than
1
/4”(6.4 cm) flame retardant millboard covered with not less than no. 28 MSG sheet steel, 0.015" (0.381 mm) stainless
steel, 0.024" (0.610 mm) aluminum or 0.020" (0.508 mm) copper.
** 15" (38.1 cm) minimum between countertop and adjacent cabinet bottom.
24”
(60.9cm)
2.5”
(6.3cm)
6”
(15.2cm)
9”
(23cm)
9”
(23cm)
11”(28cm)
15”(38cm)
4”
(10cm)
4”
(10cm)
5”
(13cm)
Wall
Center
Cabinet
Cabinet
opening
2.5”(6.3cm)2.5”(6.3cm)
6”
(15.2cm)
6”
(15.2cm)
FIGURE 1
FIGURE 1
FIGURE 2
FIGURE 2
A = 30”(76.2 cm) For U.S.A
= 30”(76.2 cm) ~ 31”(78.7 cm) For CANADA
A = 30”(76.2 cm) For U.S.A
= 30”(76.2 cm) ~ 31”(78.7 cm) For CANADA
For model : LSE Series
For model : LDE Series
