INSTALLATION
ENGLISH
Dimensions and Clearances
Provide proper clearance between the range and adjacent combustible surfaces. These dimensions must be met
for safe use of your range. The location of the electrical outlet and pipe opening (see Gas Pipe and Electrical
Outlet Locations, page 14) may be adjusted to meet specific requirements. The range may be placed with 0"
clearance (flush) at the back wall.
Maximum
depth for
cabinets
above
coutertops
Minimum
clearance
to left wall
Minimum to
cabinets on
either side
of the range
Minimum
clearance
to right wall
Front edge
of the range
side panel
forward from
cabinet
To cabinets
below
cooktop and
at the range
back
Depth with door closed
(includes door handle)
30"
(76.2 cm)
30" (76.2 cm)
Minimum
18"
(45.72 cm)
5"
5" (12.7 cm)
1
/
4
"
(0.6 cm)
28
29
/
32
"
(73.4 cm)
36"
(91.3 cm)
Height
46
1
/
2
"
(118.1 cm)
Depth with door open
47
1
/
4
"
(120.1 cm)
29
7
/
8
"
(75.9 cm)
13" (33 cm)
0"
Dimensions
Installation Clearances
36"
(91.4 cm)
