OWNER'S MANUAL
FRENCH DOOR
REFRIGERATOR
Read this owner's manual thoroughly before operating the
appliance and keep it handy for reference at all times.
ENGLISH ESPAÑOL FRANÇAIS
LRMDS3006* LRMVS3006* LRMDC2306* LRMVC2306*
MFL69497032
Rev.02_040920
www.lg.com
Copyright © 2020 LG Electronics Inc. All Rights Reserved.
us_main.book.book Page 1 Thursday, April 9, 2020 7:38 AM

Table of Contents

Questions and Answers

  • M
    Mr. Kevin ReynoldsAug 22, 2025
    What to do if my LG Refrigerator is not making ice?
    • D
      darleneedwardsAug 22, 2025
      If your LG Refrigerator's icemaker isn't producing ice, consider these points: If the refrigerator was recently installed or the icemaker was recently connected, it takes about 48 hours to start making ice. Ensure the icemaker is turned on. Check that the ice detecting sensor is not obstructed. Verify the refrigerator is connected to a water supply and the shutoff valve is fully open. Also, ensure the icemaker shutoff arm or sensor is not obstructed. Finally, if you're using a reverse osmosis water filtration system, it might be reducing the water pressure too much.
  • J
    Jeffrey AndersonAug 25, 2025
    What to do if my LG Refrigerator ice is not dispensing?
    • C
      Cindy HernandezAug 25, 2025
      If ice is not dispensing from your LG Refrigerator, first, if you are unable to hear the sound of ice coming out, select the modes for cubed ice and crushed ice alternately in the control panel to dispense the ice. Ensure all refrigerator doors are completely closed. Check the ice bin for ice cubes clumping/sticking together and break them up. Clear the delivery chute of any frost or ice fragments by removing the ice bin. Make sure the dispenser display is not locked by pressing and holding the Lock button for three seconds. Finally, ensure the ice bin is not empty and the shutoff arm/sensor is not obstructed.
  • D
    dcannonAug 26, 2025
    Why is water not dispensing from my LG LRMDS3006D?
    • C
      Curtis GarciaAug 26, 2025
      If water is not dispensing from your LG Refrigerator, if it is a new installation or the water line was recently connected, dispense 2.5 gallons of water to remove trapped air and contaminants. Ensure the dispenser panel is not locked by pressing and holding the Lock button for three seconds. Make certain that the control panel is set for water dispensing. Check that all refrigerator or freezer doors are closed properly. If the water filter was recently removed or replaced, dispense 2.5 gallons of water to remove trapped air and contaminants. Ensure the tubing connecting the refrigerator to the house supply valve is not kinked. Finally, make sure the house water supply is connected, the valve is fully open, and the valve is not clogged.
  • A
    Ashley AcevedoAug 27, 2025
    What to do if my LG Refrigerator is too warm?
    • S
      Sheri MillerAug 27, 2025
      If your LG Refrigerator is too warm, several factors could be the cause. If the refrigerator was recently installed, allow up to 24 hours for each compartment to reach the desired temperature. Check if the air vents are blocked and move any packages obstructing airflow. Reduce the frequency and duration of door openings. Ensure the unit is not installed in a hot location, as it should not be operated in temperatures above 110 °F (43 °C). Allow hot food to cool before placing it in the refrigerator. Make sure the doors are closing correctly. If the temperature is too warm, adjust the control one increment at a time and wait for the temperature to stabilize. Finally, wait 30 minutes after a defrost cycle to confirm the proper temperature has been restored.
  • J
    James McculloughAug 29, 2025
    Why is water dispensing slowly from my LG LRMDS3006D Refrigerator?
    • J
      Joan CoxAug 29, 2025
      If water is dispensing slowly from your LG Refrigerator, the water filter may be exhausted and needs replacing approximately every six months. If you are using a reverse osmosis filtration system or have low house water supply pressure, it may be necessary to contact a plumber.
  • M
    Michael FlemingAug 31, 2025
    Why is my LG LRMDS3006D food freezing?
    • J
      Jonathan ByrdAug 31, 2025
      If food is freezing in the refrigerator compartment of your LG Refrigerator, it could be because food with high water content was placed near an air vent; rearrange these items away from the vents. Check if the refrigerator temperature control is set too cold and adjust it one increment at a time, waiting for the temperature to stabilize. Also, the refrigerator should not be operated in temperatures below 55 °F (13 °C).
  • L
    Lisa EstradaSep 2, 2025
    Why is my LG LRMDS3006D dispensing warm water?
    • K
      Kelly LeeSep 2, 2025
      If your LG Refrigerator is dispensing warm water, it could be due to a few reasons: if the refrigerator was recently installed, allow 24 hours for the water storage tank to cool completely. If the water dispenser has been used recently and the storage tank was exhausted, keep in mind the water storage capacity will range from approximately 20 to 30 oz, depending on your model. If the dispenser has not been used for several hours, discard the first 10oz. Finally, make sure that the refrigerator is connected to a cold water pipe.
  • M
    Matthew DixonSep 4, 2025
    Why is my LG LRMDS3006D too cold?
    • D
      david84Sep 4, 2025
      If your LG Refrigerator or freezer section is too cold, it may be due to incorrect temperature control settings. Adjust the control one increment at a time and wait for the temperature to stabilize.
  • K
    Kevin CabreraSep 8, 2025
    What to do if my LG LRMDS3006D has moisture inside?
    • K
      Kristi OrtegaSep 8, 2025
      If you notice moisture buildup inside your LG Refrigerator, it could be due to a few reasons. Doors being opened often or for long periods can cause this; reduce how often and how long you open the doors. Ensure the doors are closing correctly. High humidity in the weather can also contribute. If a defrost cycle recently completed, wait 30 minutes to see if the temperature restores. Lastly, make sure food is correctly packaged by wiping containers dry and storing food in sealed packaging.
  • J
    josephobrienSep 9, 2025
    Why does my LG LRMDS3006D Refrigerator water taste bad?
    • M
      muellerdanielSep 10, 2025
      If the water from your LG Refrigerator has a bad taste or odor, it could be due to a few reasons. The water supply may contain minerals such as sulfur; a water filter may need to be installed. The water filter may be exhausted and needs replacing approximately every six months. If the refrigerator was recently installed, dispense 2.5 gallons of water to remove trapped air and contaminants.

Summary

Important Safety Instructions

General Safety Messages

Explains safety alert symbols, warnings, and cautions for user protection.

Installation Safety Guidelines

Details precautions for safe installation, including electrical and placement rules.

Operation and Usage Safety

Covers safe operation practices, child safety, and appliance usage rules.

Maintenance and Disposal Safety

Outlines safe practices for cleaning, maintenance, disposal, and handling of the unit.

Fire and Flammable Materials Safety

Addresses risks associated with flammable materials and potential fire hazards.

Installation

Preparation Before Installation

Covers initial steps like reading instructions and preparing the area.

Unpacking and Initial Setup

Details how to unpack the refrigerator and prepare it for installation.

Choosing the Installation Location

Guides on selecting the optimal location considering water, electricity, flooring, and temperature.

Dimensions and Clearance Requirements

Handle Removal and Installation

Door Removal and Reassembly

Water Line Connection and Finalizing

Provides detailed steps for connecting water lines and finalizing installation.

Water Line Installation and Requirements

Details water pressure, supply type, and necessary materials for installation.

Installing the Water Shutoff Valve

Connecting Water Lines and Leveling

Door Alignment Procedures

Powering On and Positioning

Operation

Before Use Checklist

A step-by-step guide for initial setup and preparation before operating the refrigerator.

Control Panel Functions

Explains the features and functions of the refrigerator's control panel.

Temperature and Filter Management

Maintenance

General Cleaning Guidelines

Provides tips for cleaning the refrigerator interior, exterior, and specific parts.

Air Filter Replacement

Instructions for replacing the fresh air filter to maintain odor control.

Water Filter Replacement Process

Detailed steps for replacing the water filter, including flushing and resetting indicator.

Troubleshooting

Frequently Asked Questions (FAQs)

Addresses common user queries regarding temperature, noises, and display issues.

Cooling System Troubleshooting

Provides solutions for common cooling problems before contacting service.

Addressing Interior Moisture and Freezing

Offers solutions for interior moisture buildup and food freezing issues.

Resolving Overheating Issues

Provides solutions for the refrigerator or freezer section being too warm.

Icemaker Ice Production and Quality

Troubleshoots ice production, quality issues, and icemaker problems.

Icemaker Ice Overproduction

Dispenser Ice and Water Flow Issues

Water Dispensing Problems

Water Quality and Component Issues

Troubleshooting Refrigerator Noises

LG LRMDS3006D Specifications

General IconGeneral
Total Capacity30 cu. ft.
ColorStainless Steel
Ice MakerYes
Water DispenserYes
Energy Star CertifiedYes
