1. Repair Instruction
Service Bulletin
b) Replace about Harness
New Harness
Distinguishing between the old and new harnesses in the target product
Old Harness : 4 Connectors in the area highlighted
New Harness : 5 Connectors in the area highlighted
New PCB
SVC Loc : A195 (New Harness + New PCB + Protect cover)
- Order the A195 (New PCB and New harness included)
Old Harness
New Harness
Page 3
Protect cover
Product : Dishwasher
Bulletin # :CDZ201900009-02
Release Date : 2019.08.20
