[SVC Notice] [Abnormal Display] 65UH5500 Model Panel Component Repair Guide
Service Bulletin
Product: LED TV
Bulletin #: GLZ202000012-01
Release Date: 02/18/2020
Applicable for Serial Number: All Serial No.
1. Repair Guide:
- Application in case of module defect, (Not including LED Array Repair).
- Order new Panel P/N instead of original panel P/N
1) Original panel P/N: (COV33685001, CRP3052070) was only supplied [Panel].
New substituted panel P/N: (COV35805501) is supplied as [Panel] + [T-CON] + [2 FFC cables] + [LVDS cable].
Page 1
Applicable for models: 65UH5500
Original Panel Part Number: COV33685001
New Panel Parts Number: COV35805501
Bulletin Type: SVC Notice Parts Others Applicable only with symptoms with every repair
Symptoms No Signal, Line Defect, Vertical Line
Cause Module defect
<Image of T-CON board , 2 FFC cables and LVDS Cable>
 
T-CON
LVDS
2 FCC

LG LRMVS2806D Specifications

General

Type	freestanding; smart cooling™ system
Style	french door; 4 door
Color	black; black stainless steel; printproof™ black stainless steel
Total Capacity	27.6 cu. ft.
Refrigerator Capacity	18.4 cu. ft.
Freezer Capacity	9.2 cu. ft.; yes
Humidity Controlled Crispers	2 humidity crispers
Defrost System	automatic
Cooling System	smart cooling, door cooling+
Number of Refrigerator Shelves	4 split(3 fixed + 1 folding)
Number of Refrigerator Door Bins	7
Number of Freezer Drawers	2-tier organization
Temperature Control	electronic/digital; yes
Temperature Sensor	6
Wine Rack	no
Interior Light	ceiling led
Dispenser	external; integrated ice & water dispenser; ice & water dispenser
Ice Maker	yes; slim spaceplus®
Water Filter	yes; lt1000p
Air Filter	yes
Door Alarm	yes
Smart Home	lg thinq, google assistant, amazon alexa
Remote Control	yes
Wi-Fi	yes
Annual Energy Consumption	760

Weight and Dimensions

Depth	36 1/4 inch
Height	69 3/4 inch
Width	35 3/4 inch
