Service Bulletin
Product : Majesty 4D
Bulletin # : CNZ201800037
Release Date : 2017.11.01
EPDM
Cover Assembly Front(251A).
4
Use a new Plate Assembly Center (loc NO 251B),and add EPDM on both sides as
picture showed, if Cover Assembly Front is broken after disassembly, use a new
Cover Assembly Front(251A). If not ,you should clean the ice on it.
press
Put it into the
case foam
5
When fixing it again , insert the right side first, then the left .
You should line up the hook and press the cover front into the plate center ,
make sure all the hooks are assembled correctly.
6
After installing the plate center, check if there is a gap
on both sides, if gap exists use silicone to seal.
To Next Page
