11
Product Data
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
Table 2: Single Zone High Efciency Standard Wall Mount System Electrical Data.
Electrical
Electrical Data
Nominal
Tons
Unit Model
No.
Hertz Voltage
Voltage
Range
(Min. to Max.)
MCA MOP
Com-
pressor
Quantity
LRA
Compressor Motor
RLA
Outdoor Fan
Motor
Indoor
Fan
Motor
Cooling Heating
W FLA FLA
3/4 LS090HSV5
60 208 - 230 187 - 253
10.0 15.0 1 7.5 7.0 7.0 43 0.4 0.4
1 LS120HSV5
10.0 15.0 1 7.5 7.0 7.0 43 0.4 0.4
1-1/2 LS181HSV5
19.0 30.0 1 17.0 12.6 14.3 124 0.78 0.4
Voltage tolerance is ±10%.
Maximum allowable voltage unbalance is 2%.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOP) is calculated as
follows: (Largest motor FLA x 2.25) + (Sum of other motor
FLA) rounded down to the nearest standard fuse size.
RLA = Rated Load Amps.
FLA = Full Load Amps.
W: Fan Motor Rated Output (W)
LRA = Locked Rotor Amps
