LG LS4400 Series Service Manual

- 7 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
No. Item Specication Remarks
2 Broadcasting system
1) PAL-BG
2) PAL-DK
3) PAL-I/I’
4) SECAM L/L’
5) DVB-T/T2/C/S
3 Receiving system
Analog : Upper Heterodyne
Digital : COFDM, QAM
► DVB-T
- Guard Interval(Bitrate_Mbit/s)
1/4, 1/8, 1/16, 1/32
- Modulation : Code Rate
QPSK : 1/2, 2/3, 3/4, 5/6, 7/8
16-QAM : 1/2, 2/3, 3/4, 5/6, 7/8
64-QAM : 1/2, 2/3, 3/4, 5/6, 7/8
► DVB-T2
- Guard Interval(Bitrate_Mbit/s)
1/4, 1/8, 1/16, 1/32, 1/128, 19/128, 19/256,
- Modulation : Code Rate
QPSK : 1/2, 2/5, 2/3, 3/4, 5/6
16-QAM : 1/2, 2/5, 2/3, 3/4, 5/6
64-QAM : 1/2, 2/5, 2/3, 3/4, 5/6
256-QAM : 1/2, 2/5, 2/3, 3/4, 5/6
► DVB-C
- Symbolrate : 4.0Msymbols/s to 7.2Msymbols/s
- Modulation : 16QAM, 64-QAM, 128-QAM and 256-QAM
► DVB-S/S2
- symbolrate
DVB-S2 (8PSK / QPSK) : 2 ~ 45Msymbol/s
DVB-S (QPSK) : 2 ~ 45Msymbol/s
- viterbi
DVB-S mode : 1/2, 2/3, 3/4, 5/6, 7/8
DVB-S2 mode : 1/2, 2/3, 3/4, 3/5, 4/5, 5/6, 8/9, 9/10
4 Scart Jack (1EA) PAL, SECAM Scart 1 Jack is Full scart and support RF-OUT(analog).
5 Video Input RCA(1EA) PAL, SECAM, NTSC 4 System : PAL, SECAM, NTSC, PAL60
6 Component Input (1EA)
Y/Cb/Cr
Y/Pb/Pr
7 RGB Input RGB-PC
Analog(D-SUB 15PIN)
Some models (LD21A,LD21C) are not supported.
8 HDMI Input (3EA)
HDMI1-DTV/DVI
HDMI2-DTV
HDMI3-DTV
PC(HDMI version 1.3)
Support HDCP
The number of Input ports is different by model.
9 Audio Input (2EA)
RGB/DVI Audio
Component & AV
In case of the RGB/DVI Audio input,
Some models(LD21A,LD21C) are not supported.
Component & AV’s audio input is used by common port.
10 SDPIF out (1EA) SPDIF out Some models(LD21A,LD21C) are not supported.
11 Earphone out (1EA)
Antenna, AV1, AV2, Component, RGB,
HDMI1, HDMI2, HDMI3
Some models(LD21A,LD21C) are not supported.
12 USB (1EA or 2EA)
EMF,
DivX HD,
For SVC (download)
JPEG, MP3, DivX HD
LM58, CM96: 2EA
LS56, LS35, CS46, LS,34, LM34 : 1EA
13 DVB
DVB-T
CI : UK, Finland, Denmark, Norway, Sweden, Russia,
Spain, Ireland, Luxemburg, Belgium, Netherland
CI+ : France(Canal+), Italy(DGTVi)
DVB-C
CI : Switzerland, Austria, Slovenia, Hungary, Bulgaria
CI+ : Switzerland(UPC,Cablecom), Netherland(Ziggo),
Germany(KDG,CWB), Finland(labwise)
DVB-S CI + : Germany(Astra HD+ )
14 Ethernet (1EA) DLNA(Wired, DMP only) Some models (LD21A,LD21C) are not supported.
