LG LS5750 Series Service Manual

- 8 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
5.2.6. HDMI 1.4a
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remark
1 1280*720p 90.00 60.00 148.50 Mandatory Frame Packing,
2 1280*720p 45.00 60.00 74.25 Mandatory Top & Bottom
3 1920*1080i 33.75 60.00 74.25 Mandatory Side by Side (Half)
4 1920*1080p 54.00 24.000 148.50 Mandatory Frame Packing,
5 1920*1080p 27.00 24.000 74.25 Mandatory Top & Bottom
6 1280*720p 45.00 60.00 74.25 Primary Side by Side (Half)
7 1920*1080i 67.50 60.00 148.50 Primary Frame Packing
8 1920*1080p 67.50 60.00 148.50 Primary Top & Bottom
9 1920*1080p 27.00 24.000 74.25 Primary Side by Side (Half)
10 1920*1080p 67.50 30.000 148.50 Primary Frame Packing,
11 1920*1080p 33.75 30.000 74.25 Primary Top & Bottom
12 1920*1080i 33.75 60.00 74.25 Secondary Top & Bottom
13 1920*1080p 67.50 60.00 148.50 Secondary Side by Side (Half)
14 1920*1080p 33.75 30.000 74.25 Secondary Side by Side (Half)
15 720*480p 63.00 60.00 54.054 Secondary (16:9) Frame Packing,
16 720*480p 31.50 60.00 27.027 Secondary (16:9) Top & Bottom
17 720*480p 31.50 60.00 27.027 Secondary (16:9) Side by Side (Half)
18 720*480p 63.00 60.00 54.054 Secondary (4:3) Frame Packing,
19 720*480p 31.50 60.00 27.027 Secondary (4:3) Top & Bottom
20 720*480p 31.50 60.00 27.027 Secondary (4:3) Side by Side (Half)
21 640*480p 63.00 60.00 50.40 Secondary Frame Packing,
22 640*480p 31.50 60.00 25.20 Secondary Top & Bottom
23 640*480p 31.50 60.00 25.20 Secondary Side by Side (Half)
24 1280*720p 90.00 60.00 148.50 Line Alternative
25 1280*720p 45.00 60.00 148.50 Side by Side (Full)
26 1920*1080i 67.50 60.00 148.50 Field Alternative
27 1920*1080i 33.75 60.00 148.50 Side by Side (Full)
28 1920*1080p 54.00 24.000 148.50 Line Alternative
29 1920*1080p 27.00 24.000 148.50 Side by Side (Full)
30 1920*1080p 67.50 30.000 148.50 Line Alternative
31 1920*1080p 33.75 30.000 148.50 Side by Side (Full)
32 720*480p 63.00 60.00 54.054 16:9 Line Alternative
33 720*480p 31.50 60.00 54.054 16:9 Side by Side (Full)
34 720*480p 63.00 60.00 54.054 4:3 Line Alternative
35 720*480p 31.50 60.00 54.054 4:3 Side by Side (Full)
36 640*480p 63.00 60.00 50.40 Line Alternative
37 640*480p 31.50 60.00 50.40 Side by Side (Full)
